KNUTH KTB 18G

Bench Drilling Machine

Order-No.SE154
MakeKNUTH
Built in2001
ConditionUsed
LocationEnnepetal - Hall 3
Delivery TermsAccording to the arrangement
QuotationFrom stock - free on truck
Priceupon request
bore capacity in steel (diameter)
16 mm
throat
180 mm

Knuth bench drilling machine KTB 18G
Knuth industrial drilling machine, Knuth bench drilling machine

Industrial drilling machine in a stable, robust design for heavy-duty use
in industry and trade
Technical data - KTB 18G - Bench drilling machine
Drilling capacity 18 mm
Drilling depth (max.) 80 mm Working area Table dimensions 235x235 mm Clamping
surface, foot (LxW) 220x190 mm Distance spindle nose table 440 mm Distance
spindle nose - foot 650 mm ) 80 mm
Working area
Table dimensions 235x235 mm
Clamping surface, foot (LxW) 220x190 mm
Distance spindle nose - table 440 mm
Distance spindle nose - foot 650 mm
Projection 180 mm
Column diameter 70 mm
Chuck diameter 13 mm
Main spindle
Speed range (9) 190 - 2800 min-1
Spindle holder MK 2 / MT 2
Drive power
Motor power main drive 1.1 kW
Supply voltage 400 V
Dimensions and weights
Height 1060 mm
Weight 80 kg
All technical information is non-binding and subject to change. Changes and
errors excepted.
