Manufacturer: KASTO
Type: SSB 260 VA
Machine type: Fully automatic band saw
Design: Hydraulic, automatic feed
Cutting range (round): approx. 10–260 mm
Cutting range (square): approx. 260 × 260 mm
Minimum cut length: approx. 5 mm
Automatic feed: approx. 600 mm
Multiple feed: up to approx. 5,400 mm (depending on version)
Cutting speed: approx. 15–125 m/min, infinitely variable
Saw band length: approx. 4,115 mm
Saw band width: approx. 38–41 mm (depending on version)
Saw band thickness: approx. 1.0–1.3 mm
Saw motor: approx. 4.0 kW
Total connected load: approx. 6.5 kW
Machine weight: approx. 2,000–2,200 kg
Dimensions: approx. 2,160 × 2,080 × 2,015 mm (depending on version)
SUBJECT TO CHANGE AND WITHOUT GUARANTEE – TECHNICAL DATA
